MXS System Description and Installation Manual UM06945
© Sagetech Avionics 2022 Proprietary Confidential Page 32 of 56
Serial Bus Type/ Required
Configuration
Main Connector Interface
Signal
Pin
RS-232 Com1
Com1-Mode pin 43 is tied to ground
Com1-232-RX
21
Com1-232-TX
22
Com1-Mode
43
Ethernet
Ethernet-TX+
23
Ethernet-RX+
24
Ethernet-TX-
48
Ethernet-RX-
49
