Sagetech MXS - Table 7-6 SQUAWK Code Logic

MXS System Description and Installation Manual UM06945
© Sagetech Avionics 2022 Proprietary Confidential Page 41 of 56
Table 7-6 SQUAWK Code Logic
System Discrete Input
User Defined Squawk Enable
Operating Message
Squawk Valid
Civil Settings Message
User Defined Squawk Valid
4096 Code Setting
De-asserted
Invalid
Invalid
1000
De-asserted
Invalid
Valid
1000
De-asserted
Valid
Invalid
Op Message Squawk
De-asserted
Valid
Valid
Op Message Squawk
Asserted
Invalid
Invalid
1000
Asserted
Invalid
Valid
Civil Settings Squawk
Asserted
Valid
Invalid
1000
Asserted
Valid
Valid
Civil Settings Squawk
• Heading and Airspeed
o Heading and airspeed information can optionally be sent in to the MXS. If this is done the
guidance in AC 20-165B must be followed.
• Altitude Rate
o Altitude rate (vertical rate) source should be sent in to the MXS following the guidance of
AC 20-165B. If vertical rate is sent through the operating message, then the MXS uses that
rate otherwise the GPS vertical rate is used.
