MXS System Description and Installation Manual UM06945

2.2 TSO Authorizations

The MXS meets the following TSO’s.

TSO

NO.

Class/Type

DO-178C/

DO-254 DAL

Function

TSO Title

C112e

Class 1

Level 2[dels]

C/C

ATCRBS / Mode S

Transponder

Airborne Equipment

Air Traffic Control Radar Beacon

System/Mode Select

(ATCRBS / MODE S) Airborne

Equipment

C166b

Class A2

C/C

1090ES MHz ADS-B

and TIS-B Equipment

Extended Squitter Automatic

Dependent Surveillance -

Broadcast (ADS-B) and Traffic

Information Service -

Broadcast (TIS-B) Equipment Operating

on the Radio

Frequency of 1090 Megahertz (MHz)

C88b

N/A

C/C

Altitude Encoder

Automatic Pressure Altitude Reporting

Code-Generating Equipment
