Chapter 2: Installation
8 Installing the Control Panel
3. Ensure that the flush mount gasket is placed correctly on the Control Panel.
4. Fit the Control Panel into the cut-out in the console.
Screw M4x65 Torx 20 (4 pcs.)
Flush Mount Bracket (2 pcs.)
Flush Mount Gasket
20Max Wall Thickness mm
