7
DSC Display Operation
Featuring a self-explanatory menu-driven system, the display guides
the user by textual instructions. Also, the function of each soft key
placed to the right of the display is shown.
Opens the address book menu.
One step back.
To go to the first screen
on the same subject.
Select ADD to ADD
make a new call
DELETE
CANCEL
AGAIN
To accept the data.
To go to the next screen
on the same subject.
Lower left corner of the
display is the data area.
Right side shows the
function of the soft keys.
Upper left corner of
the display is used for
textual instructions
Use or keyboard ACCEPT
to search in addr book
^
Ms Magretha NAME
v
TO : 219 219 219
MSG : Working CH MORE
The button opens the screen menu where all DSC calls are
stored, for up to 48 hours.
In this menu CALLS or ALARM CALLS can be read separately and
sorted according to time of reception.
The
button opens the DSC transmitter menu. From here it is
possible to make simple calls (SHORE, SHIP, ALL SHIP) and more
complicated calls including special category and telecommands.
(EXTENDED)
The
button opens the address book menu.
An ADDR BOOK call is a complete DSC call incl. a name. It is
possible to transmit, add or delete calls from here.
The
button switches between the TEL and the DSC screen.
Basic DSC Operation
DSC Main Buttons
To switch between the TEL and DSC screens, press TEL/DSC.
DSC status display or
previously used DSC display
Telephony Display
DSC status
Channel: 70
POS: N:59°09 E:009°63
At UTC: 09.14
25W
INT
MEM VOL SQ
67
6 10 03
