3
Basic Operation
Switching ON/OFF
1. Press the ON/OFF button.
In UNIT OFF mode, the VHF set is remote controlled.
To activate the panel, press ON/OFF.
Basic Telephony Operation
To activate the VHF functions if not active press the key
TEL/DSC or the key “16”.
or
Listening for Telephony Calls
According to international rules, all ships shall monitor channel 16
constantly:
1. Select channel 16 by pressing:
2. Set the squelch level by means of the button
a. Step down squelch level until noise is heard on free channel.
b. Then step up to the first level where just silent.
(To listen for calls on other channels, select the channel number
or use the scanning facility.)
25W
INT
MEM VOL SQ
16
1 10 03
25W
INT
MEM VOL SQ
16
1 10 03
