37
Installation
0505
Semifunctional Control Unit
39654
Drilling plan
100
100
36
226
80
120
min. 200
Space for handset access
Space for cable and handset cable
78
16
70
41
54
Weight :
Semifunctional Control Unit 1.2 kg
Remote control units are connected as shown on xxx.
Adding a single CU
After the CU is connected the unit can be operated straight forward without any additional
configuration.
Installing with 2 CUs
If a new installation has been made with 2 handset CUs, and the CUs are both powered for
the first time, it is important that the CUs are not turned on exactly at the same time.
If an extra new CU has been installed in a system already working with a single CU, the
already existing CU must be switched on prior to the first power-on of the new CU.
