51
Installation
0505
DSC facilities
DSC
operation
According to Rec. ITU-R M.541-9
and Rec. ITU-R M.689-2
DSC protocol
According to Rec. ITU-R M.493-11 Class A
Navigator
interface
According to IEC 61162-1
GLL, RMC, ZDA, GGA, VTG, GNS
Symbol error rate below 1*10
-2
-121 dBm or 0.20 µV p.d.
Modulation
1700
Hz ± 400 Hz
1200 baud
Frequency
error
less than ± 1 Hz
Residual
modulation
less than –26 dB
54
56
Table of Contents
Introduction
2
About this Manual
2
Abbreviations Used in this Manual
2
Quick Dsc Distress Call
3
Mayday Procedure
3
Your VHF at a Glance
4
Table of Contents
5
1 Radio Communication in Brief
7
Powering VHF
7
Operating VHF Radio Communication
7
Receiving a Call on Channel 16
7
Making a Radiotelephone Call
8
Speaker Volume
8
Earpiece Volume
8
Squelch
8
Channel Selection
9
Dual Watch
9
Replay
9
Dimming
10
Contrast
10
2 Basic DSC Operations
11
Menu Operation
11
Receiving a DSC Call
11
Transmitting DSC Calls
12
Call a Ship Station
12
Call a Shore Station
12
Direct Call to a PSTN Via a Coast Station
12
Call a Group of Ships
13
Create Emergency Calls
13
DSC Call Log
13
Entering Your Position into the System
13
3 Your VHF in Detail
15
Abnormal Power-Down
15
Settings
15
Setting Channel Mode
15
Private Channels
15
Duplex Channels
16
ATIS (Inland Waterways Only)
16
Transmitter Power
16
Channel Scanning
16
Creating Scan Tables
17
4 DSC Operations in Detail
18
MMSI Number
18
Group MMSI Number
18
Differentiating Incoming Calls by Ringing Tones
18
Working Channel
19
Contact List
19
Settings for DSC
21
Implicit Behaviour for Operations with DSC
22
Radio Configuration and Settings
24
5 Errors and Warnings
25
System Event Logging
25
Troubleshooting
26
6 Menu Tree
29
7 Optional Functional Devices
31
Semifunctional Control Unit
31
Alarm Panel
34
Printer
35
8 Maritime Channels
36
International Channels
36
US Channels
37
BI Channels
38
9 Installation
39
Mounting Possibilities
39
Interface Connections
45
Power Supply
51
Antenna Installation and Precautions
51
10 Technical Specification
54
