selection 1
Setting Options
0~0xFFFF
BIT0:Running frequency
BIT1:Setting frequency
BIT2:DC bus voltage
BIT3:Output voltage
BIT4:Output current
BIT5:Running speed
BIT6:Linear speed
BIT7:Reserved
BIT8:Reserved
BIT9:PID setting value
BIT10:PID feedback value
BIT11:Input terminals status
BIT12:Output terminals status
BIT13:Reserved
BIT14:Counter value
BIT15:Current step of multi-step
speed and PLC
F7.07
Running
status display
selection 2
Factory Setting 0
Setting Options
1~0xFFFF
BIT0:AVI value
BIT1: Reserved
BIT2: Reserved
BIT3: Motor overload ratio
BIT4: Inverter overload ratio
BIT5: Running time
BIT6: Counting meter value
BIT7~BIT15: Reserved
F7.08
Stop status display
selection
Factory Setting 3
Setting Options
0~0xFFFF
BIT0: Setting frequency
BIT1: DC bus voltage
BIT2: Input terminal status
