SAJ 8000m Series User Manual

8000m Series
- 124 -
5.13 FC Group RS485 Communication Parameters
FC.00
Local address Factory Setting 1
Setting Options 0~247
When the master node’s communication frame address is 0, it refers to the
broadcast address, and all the slave nodes will receive this frame but never reply.
Note: The address of slave node cannot be set as 0.
A local node address must be unique among the whole communication network.
This is essential for the peer-to-peer communication between a upper monitor and
VFDs.
FC.01
Baud rate selection
Factory
Setting
3
Setting Options
0 1200BPS
1 2400BPS
2 4800BPS
3 9600BPS
4 19200BPS
5 38400BPS
This parameter is used for setting of data transfer speed between upper monitor
and VFDs. Note: The baud rate settings of upper monitor and VFDs must be
identical, or communication cannot be carried out. The larger the baud rate is, the
faster the communication speed.
FC.02
Data bit check and format Factory Setting 0
Setting Options
0: No check (N, 8, 1) for RTU
1: Even parity check (E, 8, 1) for RTU
2: Odd parity check (0, 8, 1) for RTU
3: No check (N, 8, 2) for RTU
4: Even parity check (E, 8, 2) for RTU
5: Odd parity check (0, 8, 2) for RTU
FC.03 Communication response Factory Setting 0
