8000m Series
- 127 -
5.14 FD Group Multi-step Speed and Simple PLC Parameters
Simple PLC function is a programmable logic controller (PLC) in the AC drive,
which can automatically control the logic of multi-step frequency. In order to meet
the technical requirements, it can conduct running time, running direction and
running frequency. VFD can realize 16-stage speed variation control and there are
four kinds of acceleration and deceleration time for selection. When PLC
completes one cycle, ON signal can be output by multi-function digital output
terminal MO1 or multi-function relay 1. For details, see F1.02 ~ F1.05. When the
frequency reference selection is multi-speed operation mode (Parameters F0.07,
F0.03 and F0.04), it is needed to set FD.00 for required characteristic.
FD.00
Simple PLC
operation method
0:Stop after operation once
time
1:Keep the final value
after operation once time
2:Operation in cycles
0 ○
FD.01
Memory option of
simple PLC when
power-off
0: Invalid 1:Valid 0 ○
FD.02 Multi-step speed 0 -100~100% 0.10% 0.00% ○
FD.03
0th step running
time
0.0~6553s(m) 0.1s(m) 0.0s ○
FD.04 Multi-step speed 1 -100~100% 0.10% 0.00% ○
FD.05
1st step running
time
0.0~6553s(m) 0.1s(m) 0.0s ○
FD.06 Multi-step speed 2 -100~100% 0.10% 0.00% ○
FD.07
2nd step running
time
0.0~6553s(m) 0.1s(m) 0.0s ○
FD.08 Multi-step speed 3 -100~100% 0.10% 0.00% ○
