SAJ 8000m Series User Manual

8000m Series
- 27 -
＜＜
Shift key
Use it to select displayed parameters cyclically during
running or stop status. In parameter setting mode, press
this key to select the bit to be modified.
RUN/STOP
Run/Stop/Reset
key
For start, stop and reset operation, depends on control
mode setting.
3.1.3 Indicator Light Description
Indicator Light Description
Run light on: Drive running
Hz light on: Frequency Display
V light on: Voltage Display
A light on: Current Display
3.2 Operation Details
3.2.1 Parameter Setting
Three levels of menu are as following:
· Function code group (first-class)
· Function code (second-class)
· Setting parameter of function code (third-class)
Remarks:
Pressing PRGM or ENT can return to the second-class menu from the third-class
menu. The difference is: Pressing ENT will save the setting parameters into control
board, and return to the second-class menu with shifting to the next function code
automatically. While pressing PRGM will directly return to the second-class menu
without saving the parameters, and keep staying at the current function code.
