SAJ 8000m Series User Manual

8000m Series
- 81 -
5.6 F5 Group Input Terminals Parameters
The standard unit of a 8000m series VFD has 4 multi-function digit input terminals
and 1 analog input terminal.
F5.00 M1 terminal function Factory Setting 1
F5.01 M2 terminal function Factory Setting 2
F5.02 M3 terminal function Factory Setting 7
F5.03 M4 terminal function Factory Setting 0
F5.04 Reserved Factory Setting 0
F5.05 Reserved Factory Setting 0
F5.06 Reserved Factory Setting 0
F5.07 Reserved Factory Setting 0
F5.08 Reserved Factory Setting 0
F5.09 Reserved Factory Setting 0
These parameters are used to set the corresponding functions of digit multi-function
input terminals or virtual multi-function digital input, the optional functions are as
follows:
Setting
Values
Functions Descriptions
0 No function
Even has signal input, the VFD will not act. The
unused terminals can be set as no function in case
of preventing malfunction.
1 Run forward (FWD)
Control terminals for running forward and
reverse.
2 Run reverse (REV)
3 3-wire control
The terminal determines the operation mode of
AC drive as 3-wire control. For details, please
refer to the description of function code of F5.11
3-wire control.
4 Jog forward (FJOG) FJOG is jog forward operation, RJOG is jog
