Please ensure that the air at the installation point is circulated. Bad air ventilation
will affect the working performance of internal electronic components and shorten
the service life of AS1.
Fig. 3.4 Installation distance
3.3 Installation Steps
3.3.1 Determine the mounting hole position of the hanging panel
The AS1 series is mounted on a hanging panel. The mounting position is
determined according to the position of the hanging hole on the hanging panel.
Choose either 239mm holes (away from center) or 300mm holes (away from
center) to install. Unit: mm.
