Section 1
Components and
Specifications
Power Supply Requirements
Model 8030 AutoWrite Slide Printer
Rated Voltage and Current:
AC 100-120 V
10%, 50-60Hz, 4.0 Amps
AC 200-240 V
10%, 50-60Hz, 2.8 Amps
Admissions:
All instrument-specific admissions are located on the
rear panel of the instrument.
Maximum Power Draw: 480 VA
Fuse Rating:
2 x 3.15 A T (UL-listed)
Safety Standards
Complies with: IEC 61010-1 2
nd
ed., CAN/CSA C22.2 No.
1010.1-92, UL 61010A-1
Dimensions
Without Magazine:
Centimeters: 41(W) x 58(D) x 46(H)
Inches:
16.1(W) x 22.8(D) x 18.1(H)
With Magazine Slide Printer:
Centimeters: 41(W) x 58(D) x 56(H)
Inches:
16.1(W) x 22.8(D) x 22(H)
Instrument Weight
Weight, unpacked: Approx. 28 kg (62 lbs)
Weight, packed:
Approx. 65 kg (143 lbs)
Unload Station
Weight, unpacked: Approx. 14 kg (31 lbs)
Weight, packed:
Approx. 32 kg (71 lbs)
Computer Requirements
Type:
PC Pentium III or higher
Processor Clock Rate: 800 MHz (minimum)
Main memory RAM:
512MB (recommended) 256MB
(minimum)
Hard Drive:
6GB of free hard drive space
(minimum)
Operating Systems:
Windows®
1
NT 4.0 (sp 6+),
Windows 2000, Windows XP Pro,
Windows Vista, Windows 7
1
Microsoft, Windows and Access are registered trademarks of
the Microsoft Corporation.
Printer Interface:
Serial connection via serial port
(RS 232C)
Drive Type:
CD ROM (mandatory for system
upgrades)
Software:
Microsoft Access®-version 2002
(recommended)
Operating Conditions
Operational Temperature: 15
C to 35
C (59
F to 95
F)
Relative Humidity:
30-80% (non-condensing)
Atmospheric Pressure:
80kPa – 106kPa
Storage Temperature:
0
C to 50
C (32
F to
122
F)
Storage Relative Humidity: 15-90% (non-condensing)
Protect from direct sunlight
Performance Data
Load Capacity:
3 magazines, 150 slides per magazine
Print Speed
2
:
Batch–job printing:
15 slides per minute
Single-slide printing:
10 seconds per slide
Ink Cartridge Capacity:
60,000 print jobs or 3.5 months whichever comes first
Curing Lamp Lifespan:
Approx. 150,000 flashes
Print Resolution
3
:
360 x 360 dpi/180 x 180 dpi, Selectable
Printable Objects:
Non-beveled edge glass microscope slides 75 x 25
mm, max. 1.2 mm in thickness
Print Formats:
Slide
Print Surface:
Max. 25.4 x 18.0 mm
2
Average value-exact speed in each individual case depends on
system configuration and software used.
3
Measured in addressable dots per inch.
Revised 3/04/11 1.11
