CARE OF THE INSTRUMENT
Slide Debris Tray
Periodically remove and empty the slide debris tray
(Figure 6-B).
Removal and
Replacement
Removing and Replacing the Curing Lamp
Code 13 appears on the instrument display when the
curing lamp reaches the limit of its rated service life. When
this code is issued, the lamp must be changed.
Unload Station
Figure 6-B
Removing the Curing Lamp
CAUTION: Switch instrument OFF and unplug the
power cord before beginning.
CAUTION: Allow the curing lamp to cool before
attempting to remove.
CAUTION: Always wear gloves when touching the
curing lamp to prevent damage to the
lamp.
1.
Open the main cover of the instrument exposing the
main components.
2.
Locate the reflective cover housing the curing lamp.
The Unload Station (Figure 6-C) enables organized
and automatic collection of slides.
Remove dust and debris from the guides and ejector
with a brush.
The unload tray can be cleaned with a household
cleaner.
NOTE:
Do not use any solvents or bleach to clean the
trays. Trays must be completely dry prior to use.
Figure 6-C
3.
Using the screwdriver provided, remove the screw
and washer located at the bottom of the reflective
cover (Figure 6-D).
Figure 6-D
4.
Open the reflective cover by moving it upwards.
To Next Page
