OPERATING INSTRUCTIONS
Printing Sli
d
es
Print commands are issued by the PC connected to the
slide printer.
NOTE:
A print job cannot be completed unless the
[ONLINE] LED is illuminated. If the LED is not illuminated,
press the [ONLINE] key.
1.
Open the application (program) to be used for data
entry and enter the information to be printed on one
or more slides.
2. From the
File
menu, select
Print
and then click
OK
.
The slide is pushed by the ejection arm from the
magazine into the delivery chute. The slide moves down the
delivery chute and is held in the transfer point until the print
sledge becomes available. As the print sledge moves to the
transfer point, an arm drops down allowing the slide to fall
into the print sledge. The print sledge moves under the print
head, where the printing occurs. Once the information has
been printed on the slide, the print sledge moves the slide
to the drying station. The drying station blows warm air on
the freshly printed slide to dry the ink. The slide is then
dropped in the final station, where a UV curing lamp is
activated and cures the ink.
The slide drops into the slide bin or is delivered onto
the unload slide tray.
Interrupting a Print Job
To interrupt a print job
There may be occasions when a print job needs to be
interrupted so that the printer can be accessed for
maintenance or error elimination.
1.
On the slide printer, press the
[ONLINE]
key (Figure
4-D).
Figure 4-D
Printing is interrupted.
0
2.
Clear any errors or perform needed maintenance, and
then press
[ONLINE]
key again.
Printing resumes.
0
