Sakura Tissue-Tek Autowrite User Manual

Revised 3/04/11
2.13
Section 2
Filling and Loading the Slide
Magazines
5. Fill the magazine by placing the slides with the
surface to be printed facing upwards and toward the
left.
NOTE: The magazines can hold up to 150 slides
(depending on individual slide thickness). Fill up to the
maximum level mark on the magazine.
NOTE: Slides can be loaded one at a time with the
magazines off the instrument (Figure 2-LL), or while the
magazines are on the instrument (Figure 2-MM).
Figure 2-LL
Figure 2-MM
6. Hold the magazine tipping it slightly to prevent slides
from falling out of the magazine.
7. Insert the magazine into the receptacle by aligning
the pins into the slot, and lowering until locked into
place. See Figure 2-MM through Figure 2-PP.
Figure 2-NN
Figure 2-OO
Figure 2-PP

Sakura Tissue-Tek Autowrite Specifications

General

Brand	Sakura
Model	Tissue-Tek Autowrite
Category	Printer
Language	English
