Section 1
Ink/Transport Cartridge Receptacle
(Figure 1-I)
The transport cartridge is inserted in the cartridge
receptacle when the instrument is transported. For routine
operation, the transport cartridge must be replaced by an
ink cartridge.
Figure 1-I
Slide Debris Tray (Figure 1-J)
The slide debris tray collects debris that accumulates
during the printing of multiple slides.
Transport Cartridge (Figure 1-K)
The transport cartridge is needed to keep the print head
from drying out during transportation or when the
instrument will not be used for an extended period of time.
Figure 1-J
Figure 1-K
