Sakura Tissue-Tek Glas g2 User Manual

Section 1
Revised 3/30/2010 1.7
Specifications
Models
Model Name/Description
6500
Tissue-Tek
®
Glas
™
g2 Automated Glass Coverslipper
(115 VAC) (USA)
6501
Tissue-Tek
®
Glas
™
g2 Automated Glass Coverslipper
(100 VAC) (Asia)
6502
Tissue-Tek
®
Glas
™
g2 Automated Glass Coverslipper
(230 VAC) (Europe)
Power Supply Requirements
Model Power Frequency Amps
6500 115 VAC ± 10% @ <15A 50/60 Hz 2.2A
6501
100 VAC + 10%/−5% @ <15A
50/60 Hz
2.5A
6502
230 VAC ± 10% @ < 7A
50/60 Hz
1.2A
Electrical Safety
For Model 6500 –
cETL Certification
• Safety requirements UL61010A-1:2004,
• CAN/CSA-C22.2 No.61010-1:2004
For Model 6501 –
CE Marking
• Safety requirements IEC61010-1:2001
• EMC Directive IEC61326-1:2002
• In-vitro Diagnostic Directive IEC61010-2-101:2002
• Risk management ISO14971:2000
For Model 6502 –
Amendment of Pharmaceutical Affairs Law
• Safety requirements J IS C1010-1:2005
• EMC JIS C1806-1:2001
• Risk management JIS T14971:2003
Dimensions
750 (W) x 620 (D) x 750 (H) mm
Instrument Weight
Approximately 110 kg (242.5 lbs)
Operating Conditions
Operational Temperature: 10°C to 40°C (50°F to 104°F)
Relative Humidity: 30-85% (non-condensing)
Protect from direct sunlight
Capacity
Coverslipping Speed: up to 420 slides/hour
Acceptable Dimensions for Slides
Dimensions:
25.0 to 26.0 (width) x 75.0 to 76.0 (length) mm
Thickness:
0.9 to 1.2 mm
Acceptable Dimensions for Cover Glass
Dimensions:
24 (width) x 40, 50, 55, 60 (length) mm
25 (width) x 40, 50, 55, 60 (length) mm
If 25-mm wide cover glasses are used, the system may
have to be readjusted.
Thickness:
0.9 to 1.2 mm
Compatible Solvent
Xylene
D-Limonene-based substitutes
Aliphatic-Hydrocarbon-based substitutes
Compatible Mounting Medium
Xylene-based mounting medium
D-Limonene-based mounting medium
Aliphatic-Hydrocarbon-based mounting medium
