Salda Smarty 2X V Series User Manual

22
Smarty 2X/3X V
www.salda.lt
The system records 50 recent events (failures, alarms, re damper testing results, etc.). The log stores the event description and time.
Every unit has a conguration version specic to this unit, which is saved in the production line. Besides the system conguration and software ver-
sions the running time is also displayed since the unit manufacture date. Running time is calculated when fans are rotating.
4 air ows are used in the system and they are dedicated to specic modes:
1. Building protection
2. Economy
3. Comfort
4. “BOOST” function
The ows are displayed in ascending order, i.e. when “Comfort” mode is set to lower air ow than that of “Economy” one, the “Economy” mode air ow
will be reduced automatically. With respect to the system conguration, air ows are indicated in percentage or pressure or amounts of air. 100% value
of air ow is indicated in service environment.
A12 #D26 EXHAUST AIR TEMPERATURE SENSOR FAILURE. SYSTEM STOPPED.
A13 #D27 OUTSIDE AIR TEMPERATURE SENSOR FAILURE. SYSTEM STOPPED.
A14 #D28 HYDRAULIC HEATER WATER TEMPERATURE SENSOR FAILURE. SYSTEM STOPPED.
A15 #D29 HYDRAULIC PREHEATER WATER TEMPERATURE SENSOR FAILURE. SYSTEM STOPPED.
A16 #D30 HYDRAULIC COOLER WATER TEMPERATURE SENSOR FAILURE. SYSTEM STOPPED.
A17 #D31 CONTROLLER CABINET TEMPERATURE SENSOR FAILURE. SYSTEM STOPPED.
A18 #D34 HEATER MANUAL PROTECTION. SYSTEM STOPPED.
A19 #D36 PREHEATER MANUAL PROTECTION. SYSTEM STOPPED.
A20 #D38 SUPPLY FAN PROTECTION
A21 #D39 EXTRACT FAN PROTECTION
A22 #D40 DX COOLER PROTECTION
A23 #D41 FIRE ALARM
A24 #D42 SUPPLY AIR PRESSURE PROTECTION. SYSTEM STOPPED.
A25 #D43 EXTRACT AIR PRESSURE PROTECTION. SYSTEM STOPPED.
A26 #D44 BAD CONFIGURATION
A27 #D45 HEATER MANUAL PROTECTION: FAN BOOST ENABLED
A28 #D46 PREHEATER MANUAL PROTECTION: FAN BOOST ENABLED
WARNING
NO REGISTER NAME
W1 #D1 BROKEN ROTOR BELT (Applicable when a rotor heat exchanger is built in the unit).
W2 #D3 DRYNESS PROTECTION ACTIVATED
W3 #D4 PLATE HEAT EXCHANGER FROST PROTECTION ACTIVATED
W4 #D8 TOO LOW SUPPLY TEMPERATURE
W5 #D9 TOO HIGH SUPPLY TEMPERATURE
W6 #D14 CHANGE SUPPLY AND EXTRACT FILTERS
W7 #D16 SUPPLY AIR TEMPERATURE SENSOR FAILURE. EMERGENCY RUN.
W8 #D17 EXTRACT AIR TEMPERATURE SENSOR FAILURE. EMERGENCY RUN.
W9 #D18 EXHAUST AIR TEMPERATURE SENSOR FAILURE. EMERGENCY RUN.
W10 #D19 OUTSIDE AIR TEMPERATURE SENSOR FAILURE. EMERGENCY RUN.
W11 #D20 HYDRAULIC HEATER WATER TEMPERATURE SENSOR FAILURE. EMERGENCY RUN.
W12 #D21 HYDRAULIC PREHEATER WATER TEMPERATURE SENSOR FAILURE. EMERGENCY RUN.
W13 #D22 HYDRAULIC COOLER WATER TEMPERATURE SENSOR FAILURE. EMERGENCY RUN.
W14 #D23 CONTROLLER CABINET TEMPERATURE SENSOR FAILURE. EMERGENCY RUN.
W15 #D32 FIRE DAMPER TEST PASSED
W16 #D33 FIRE DAMPER TEST FAILED
W17 #D35 HEATER AUTOMATIC PROTECTION
W18 #D37 PREHEATER AUTOMATIC PROTECTION
