Salda Smarty 2X V Series User Manual

36
Smarty 2X/3X V
www.salda.lt
DRAWN BY
CHECKED BY
SIGNATUREDUTIES / NAME DATE
UAB"SALDA"
Drawing #
Book #
CHECKED BY
1 1 2 3 4 4 5 6 7 7
EI D. Aleksandravičius
EI A. Šklenikas
Fans (MiniMCB)
SP42
Principle connection scheme
12
01
2016-03-22
2016-03-22 2016-03-22
BK - Black - Juodas BN - Brown - Rudas
GY - Grey - Pilkas
WH - White - Baltas
BU - Blue - Mėlynas RD - Red - Raudonas
GN/YE - Green/Yellow - Žalias/Geltonas
PE
N
L1
+10V
Tach
GND
0-10V in
PV
H4)
PE
N
L1
+10V
Tach
GND
0-10V in
IV
H4)
Cable for power supply
Cable for control
Cable for power supply
Cable for control
X15:1 - PE
X15:2 - N(L1)
X15:3 - DO6(L(L2))
N1
miniMCB V0.3
X16:1 - DO6(L(L2))
X16:2 - N(L1)
X16:3 - PE
N1
miniMCB V0.3
X2:1 - GND
X2:2 - AO1(0-10V)
X2:3 - GND
X2:4 - AO2(0-10V)
N1
miniMCB V0.3
X4:1 - DI2(Tacho1_A)
X4:2 -Tacho1_K
X4:3 - DI3(Tacho2_A)
X4:4 -Tacho2_K
N1
miniMCB V0.3
White
0.35
Red
0.35
White
0.35
Red
0.35
Yellow
0.35
Blue
0.35
Yellow
0.35
Blue
0.35
Brown | Black
0.5
Green-yellow
0.5
Blue
0.5
Brown | Black
0.5
Blue
0.5
Green-yellow
0.5
