Salda Smarty 2X V Series User Manual

45
Smarty 2X/3X V
www.salda.lt
Functions are activated with external switches.
Automation controller A zone.
System mode switch X7: 1, 2
Fan speed switch X7: 3, 4
Pre-Heater Capacity by Regions
Product T
R
,
o
C
V
n
,
m
3
/h
t
1
,
o
C
befor
pre-
heater
t
2
,
o
C
supply
after pre-
heater
P
sk
, W I, A U,V
Flange
diamet-
er
Preheater Connection scheme
Smarty 2XV
up to
-3
121 -3 -2 44 0,19 230 1f 125
External pre-heater is not neces-
sary, unit 1.1 version with internal
pre-heater 0.6 kW is suitable
-
up to
-15
121 -15 -2 566 2,46 230 1f 125
up to
-25
121 1002 125
EKA 125-1,2-1f GKOEKA051 219.1017.0.1.2-PS-0k
-25 -2 4,36 230 1f EKA NIS 125-1,2-1F PSIEKANIS20 SP45
up to
-40
121 1655 125
EKA 125-1,8-1f GKOEKA047 219.1017.0.1.2-PS-0k
-40 -2 7,20 230 1f EKA NIS 125-1,8-1F PSIEKANIS22 SP45
Smarty 3XV
up to
-3
261 -3 -2 94 0,41 230 1f 160
External pre-heater is not neces-
sary, unit 3.1 version with internal
pre-heater 1.2 kW is suitable
-
up to
-15
261 -15 -2 1221 5,31 230 1f 160
up to
-25
261 -25 -2 2161 9,40 230 1f 160 EKA NIS 160-5,0-2F PSIEKANIS27 SP45
up to
-40
261 -40 -2 3570 15,52 230 1f 160 EKA NIS 160-5,0-2F PSIEKANIS27 SP45
P
sk
- Calculated power consumption, W
T
R
- Regions based on outdoor air temp.,
o
C
V
n
- Nominal unit air ow, m
3
/h (G4 lter)
Supply air CO
2
or RH (input 0-10VDC) connection. This connection is possible for unit version 1.1 miniMCB basic with EX1
controller.
Installation diagram.
Transmitter shall be installed inside supply air duct.
Wiring diagram.
Automation controller B zone X19.
Supply air CO2 or
RH (input 0-10VDC)
+24VDC
GND
1 2 3
AI1(0-10V)
Vin
GND
AO1
Transmitter 2
