PRODUCT SPECIFICATION
Model: SP220
Type: Dual channel programmable heating controller
designed for 230V AC heating applications.
CLOCK
Type: Radio Controlled (RCC).
Reception Frequency: 60 kHz ± 300 Hz
Display Modes: 12 or 24 hour clock with Day of Week display.
PROGRAMMING
Programming Modes: User selectable for individual, 5/2 or 7 day options
Number of Programmes: Three (3) user programmes each day.
Holiday Facility: User selectable option to temporarily override selected programme.
MODES
Operating Modes: Pumped (P) or Gravity (G) modes
Default Setting: P mode
DEFAULT PROGRAMMES (HEATING AND HOT WATER)
Programme Output Weekday Weekend
1 ON 6:00 AM 6:00 AM
OFF 8:00 AM 8:00 AM
2 ON 10:00 AM 10:00 AM
OFF 12:00 PM 12:00 PM
3 ON 6:00 PM 6:00 PM
OFF 10:00 PM 10:00 PM
29SP220 INSTRUCTION MANUAL
