AIS 3410, Electronics Unit
ED3047G842 / 01 (2009-08)
Technical Manual
4 Functional Description
4.3 Description of the Components
t_ue_e04.fm / 27.08.09
36
Input sentences in compliance with IEC 61162-1/-2
NOTE:
If the AIS Electronics Unit receives the ship’s sensor data from Ship’s Interface, the output interfaces of
the Ship’s Interface must be configured as follows:
- Select "IEC 61162-1 edition 3/2007 (NMEA 3.01)" as driver
- Set a repetition interval of 1 s for the following telegrams: GLL, VTG, HDT, ROT, VBW
Data
Required Sentence
(Identifier and Description)
Optional Sentence
(Identifier and Description)
Reference Datum DTM (Datum reference)
Positioning System:
- Time of Position
- Latitude/Longitude
- Position accuracy
- GNS (GNSS fix data)
- GLL (Geographic position latitude/
longitude)
- RMC (Recommended minimum
specific GNSS data)
Speed over Ground (SOG) - VBW (Dual ground/water speed) - VTG (Course over ground and ground
speed)
- RMC (Recommended minimum
specific GNSS data)
Course over Ground (COG) - RMC (Recommended minimum
specific GNSS data)
- VTG (Course over ground and ground
speed)
Heading - HDT (Heading, true)
RAIM indicator - GBS (GNSS satellite fault detection)
Rate of Turn (ROT) - ROT (Rate of turn)
