AIS 3410, Electronics Unit
ED3047G842 / 01 (2009-08)
Technical Manual
8 Fault Code List
t_ue_e09.fm / 27.08.09
64
029
AIS: No valid SOG
information
AIS NO SOG
Generated by: AIS Electronics Unit
Cause/Source: No data from external sensor and from
internal position sensor
Reaction: The Electronics Unit continues operation.
Remedy: The telegrams VBW, VTG, RMC can not be
received. Check the sensor and the cabling; Check if the
system that transmits the data is working (RADARPILOT
1x00); Check the baud rate settings of the sensor inputs.
030
AIS: No valid COG
information
AIS NO COG
Generated by: AIS Electronics Unit
Cause/Source: No data from external sensor and from
internal position sensor
Reaction: The Electronics Unit continues operation.
Remedy: The telegrams VTG, RMC can not be received.
Check the sensor and the cabling; Check if the system that
transmits the data is working (RADARPILOT 1x00); Check
the baud rate settings of the sensor inputs.
032
AIS: Heading lost/
invalid
AIS NO HEADING
Generated by: AIS Electronics Unit
Cause/Source: No data from external sensor
Reaction: The Electronics Unit continues operation.
Remedy: The telegrams HDT can not be received. Check the
sensor and the cabling; Check if the system that transmits
the data is working (RADARPILOT 1x00); Check the baud
rate settings of the sensor inputs.
035
AIS: No valid ROT
information
AIS NO ROT
Generated by: AIS Electronics Unit
Cause/Source: No data from external sensor
Reaction: The Electronics Unit continues operation.
Remedy: The telegrams ROT can not be received. Check the
sensor and the cabling; Check if the system that transmits
the data is working (RADARPILOT 1x00); Check the baud
rate settings of the sensor inputs.
051
AIS: Channel
management infor
-
mation not accepted
AIS SET CHANNELS
Generated by: AIS Electronics Unit
Cause/Source: E.g. overlapping with an existing area
Reaction: The Electronics Unit continues operation.
Remedy: Check the channel management information.
052
AIS: GPS receiver
fault
AIS GPS RECEIVER
Generated by: AIS Electronics Unit
Cause/Source: Internal GPS receiver malfunction
Reaction: The Electronics Unit continues operation without
internal GPS data and without direct GPS time synchroniza-
tion.
Remedy: The Electronics Unit must be exchanged.
053
AIS: GPS antenna
not connected or
defective
Generated by: AIS Electronics Unit.
Cause/Source: No connection with the GPS antenna
Reaction: The AIS Electronics Unit continues operation
without direct GPS syncronisation.
Remedy: Renew proper connection with the GPS antenna
and/or substitute the defective GPS antenna.
Fault
Messages at
Error Message generated by,
Possible Cause/Source,
Reaction of the System,
Remedy
1000/1100 Series,
CHARTPILOT,
MULTIPLOT 910x
(Chart Mode)
Radar 9xxx, MULTIP-
ILOT 910x (Radar
Mode)
