10 PCB Layout and Parts List
10-4 SAM4S ER-5200 Series
10-1 Main PCB Layout
10-1-1-(b) Parts List
No Parts-No Description/Specification Q'TY Design-Location Serviceable Remark
-
2203-000192 C-CERAMIC,CHIP:100nF,+80-20%,50V,Y5V,TP, 44
C1,C2,C3,C11,C18,C19,C2
5
C26,C29,C31,C33,C34,C37
C39,C40,C42,C47,C48,C50
C52,C55,C56,C57,C58,C60
C62,C63,C64,C67,C68,C69
C70,C75,C79,C80,C81,C89
C35,C45,C53,C59,C65,C71
C84
Y
-
2203-000239 C-CERAMIC,CHIP:0.1nF,5%,50V,NP0,TP,2012 16
C6,C7,C8,C9,C10,C14,C16
C21,C22,C24,C32,C36,C38
C5,C12,C13,C23,C41
Y
-
2203-000260 C-CERAMIC,CHIP:10nF,10%,50V,X7R,TP,2012 3 C43,C44,C49
Y
-
2203-000634 C-CERAMIC,CHIP:0.022nF,5%,50V,NP0,TP,201 2 C46,C51
Y
-
2203-000748 C-CERAMIC,CHIP:0.03nF,5%,50V,NP0,TP,2012 2 C72,C74
Y
-
2203-000938 C-CERAMIC,CHIP:0.47nF,5%,50V,NP0,TP,2012 5 C54,C73,C76,C77,C78
Y
-
3301-000317 CORE-FERRITE BEAD:AB,2x1.25x0.9mm,-,- 53
L1,L2,L3,L4,L5,L6,L7,L8,L9
L10,L11,L12,L13,L14,L16
L17,L18,L19,L21,L22,L23
L24,L26,L27,L28,L29,L31
L32,L33,L34,L36,L38,L40
L41,L42,L43,L44,L46,L47
L48,L49,L51,L52,L53,L54
L15,L20,L25,L30,L35,L45
L50,L55
Y
-
JK41-10544A PCB-MAIN:ER-5200/5500,FR-4,2L,T1.6mm,221 1 MAIN PCB
Y
-
0202-000108 SOLDER-CREAM:RMA-010 T-322,S63,-,- 1 MAIN PCB
Y
-
0201-001235 ADHESIVE-TS:DEH-390D,RED,400,- 1 MAIN PCB
Y
