Step 10
Remove the seal from the liner.
Use a flat screwdriver.
NOTE:
Be careful not to scratch the liner or damage the seal groove.
Possible residues or seal deposits caused by the removal of the
seal with the screwdriver.
Step 11
Check that there are no deposits or residues in the liner.
Blow a blower if necessary.
Place the seal in the liner at an angle of approximately 45 degrees.
Then seal it once in the liner:
Use the air needle to properly position this seal in the liner.
Apply grease to the air needle tip and its cylindrical body.
Then put the needle back into the liner according to its original position.
560440001 : PTFE grease 450 GR. box
560440101 : 10 ML GREASE PTFE CARTRIDGE
