Adjusting the air ow direction
Air ow can be directed to your desired position.
Vertical air ow
Air ow blades move up and down.
Press the Vertical air swing button on the remote controller.

Air swing indicator will be on the remote controller display and air ow blades move
up and down continuously to circulate the air.
 
Press the Vertical air swing button on the remote controller again, to keep the
air ow direction in a constant position.

If you adjust the vertical air ow blade manually, it may not close completely when
you turn o the air conditioner.
• Adjustingtheairowdirectionisnotavailableingood'sleepmodewhileitisin
cool mode.
• However,youcanadjusttheairowdirectioningood'sleepmodewhileitisin
heat mode. ( ARHP)
Horizontal air ow
Make sure one of the blade pin lever that stick out of the air ow blades are not broken.
Move the blade pin lever left or right to keep the air ow direction in a constant
position you prefer.
• BeextremelycarefulwithyourngerswhileadjustingtheHorizontal
air ow direction.
There is a potential risk of personal injury when the unit is
mishandled.
Blade pin lever
