Samsung FER710DRS - Removing the Panel-Side

28
3. Disassembly and Reassembly
3-17 Removing The Panel-Side
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing the range. Replace all panels before operating range. Failure to do so
can result in death or electrical shock.
PRECAUTION
When you work on the electric range, be careful when handling the sheet metal parts. Sharp edges may
be present, and you can cut yourself if you are not careful.
Parts Explanation Photo Explanation
Panel
Side
Panel Side
1. Turn off the electrical supply.
2. Remove the oven door from the range
(see page 3-15 for the procedure).
3. Pull the range away from the wall so
you can access the back of the unit.
4. Remove the 8 screws from the rear of
Panel-Side and remove Cooktop.
5. Remove the (each) 3screws from the
top the Panel-Side.
6. Pull the back of the side panel out from
WKHUDQJHDSSUR[LPDWHO\Û
7. Push forward and remove Panel-Side.
* Reassembly of All part is the reverse order of disassembly.
