Samsung FER710DRS - PCB Diagrams (Sub)

52
5. PCB Diagrams
5-2 PCB Diagrams (Sub)
(This Document can not be used without Samsung’s authorization)
No. Parts Number Part Name Function and Rule
1 TE400 Main Communication Connector This is connector which is connected with Main PCB to communicate.
2 CN200 On Board Writing Connector When do micom revision, connect to micom writer. (No connection at normal times)
