Explain primary parts of Sub PCB
Explatin of the function of primary parts.
TE400 This is connector which is connected with Main PCB to communicate.
CN400
When do micom revision, connect to micom writer.
(No connection at normal times)
CN200
When do micom revision, connect to micom writer.
(No connection at normal times)
CN502 This is connector which is connected with cooktop and Main cooling motor.
TE400 CN400 CN200 CN502
