Samsung HT-J4530 - Specifications

41 - English
Appendix
General
Weight 1.90 kg
Dimensions 430.0 (W) x 55.0 (H) x 224.0 (D) mm
Operating Temperature Range +5°C to +35°C
Operating Humidity Range 10 % to 75 %
FM Tuner
Signal/noise ratio 55 dB
Usable sensitivity 12 dB
Total harmonic distortion 1.0 %
HDMI
Video 1080p, 1080i, 720p, 576p/480p
Audio PCM multichannel audio, Bitstream audio, PCM audio
Amplifier
Front speaker output 80W x 2 (3Ω)
Centre speaker output 80W (3Ω)
Surround speaker output 80W x 2 (3Ω)
Subwoofer speaker output 100W (3Ω)
Frequency response
Analogue input : 20Hz~20kHz (±3dB)
Digital input : 20Hz~40kHz (±4dB)
S/N Ratio 70dB
Channel separation 60dB
Input sensitivity (AUX) 500mV
Speaker
Speaker system
5.1ch speaker system
Front Surround Center Subwoofer
Impedance 3 Ω 3 Ω 3 Ω 3 Ω
Frequency range 140Hz~20kHz 140Hz~20kHz 140Hz~20kHz 40Hz ~ 160Hz
Output sound pressure level 87dB/W/M 87dB/W/M 87dB/W/M 88dB/W/M
Rated input 80W 80W 80W 100W
Maximum input 160W 160W 160W 200W
Dimensions
(W x H x D)
(Unit : mm)
HT-J4500
77 x 108 x 70 77 x 108 x 70 228 x 77 x 70 155 x 300 x 285
HT-J4530
95 x 1112 x 74.5 77 x 108 x 70 228 x 77 x 70 155 x 300 x 285
HT-J4550
95 x 1112 x 74.5
(stand base)
276 x 189
95 x 1112 x 74.5
(stand base)
276 x 189
228 x 77 x 70 155 x 300 x 285
Weights
(Unit : kg)
HT-J4500
0.35 0.35 0.49 2.88
HT-J4530
2.7 0.35 0.49 2.88
HT-J4550
2.7 2.7 0.49 2.88

✎
Network speeds equal to or below 10Mbps are not supported.

✎
Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.

✎
Weight and dimensions are approximate.

✎
Design and specifications are subject to change without prior notice.

✎
For the power supply and Power Consumption, refer to the label attached to the product.
