PROBLEM SOLVING
Clearing Paper Jams
3
If you cannot find the jammed paper in
the Tray 2, pull the upper Tray 1 half
way out of the printer, and remove the
paper as shown in the figure at right.
In the Optional Tray 2
1
Pull the option Tray 2 out of the printer.
2
If you see the jammed paper, remove
the paper from the tray.
4
Slide the trays back into the printer.
Open the top cover, then close it again.
Printing can be resumed.
7.14
To Next Page
