Memory and PostScript DIMMs
Additional printer memory and the PostScript option are provided on DIMMs (dual in-line
memory modules). This procedure is applicable to either option.
1
Turn the printer power off and unplug
all cables from the printer.
2
Remove the two screws on the rear of
the printer, then remove the control
board cover.
3
Locate the PS DIMM slot (the upper slot
on the right as shown) and the memory
DIMM slot (the lower slot) on the control
board. They are not interchangeable.
• To install the PS DIMM, continue with
Step 4.
• To install the memory DIMM, go to
Step 5.
PS DIMM
Memory
H.2
PRINTER OPTIONS
