3.
Disassembly
and
Reassembly
3.3.18.2.
Lift
Unit
1.
Remove
the
SCF
cassette.
2.
Remove
3
screws.
3.
Remove
the
Cover
Dummy
Front.
4.
Remove
2
screws.
Then,
remove
the
Cover
-Right.
5.
Remove
7
screws.
Then,
remove
the
Frame
Dummy
Right.
6.
Remove
4
screws.
Then,
release
the
Lift
Unit.
3-29
Copyright©
1995-2017
SAMSUNG.
All
rights
reserved.
79
81
