Compressor → condenser → Hot Pipe → Dryer → Capillary Tube → Refrigerator Evaporator → Freezer
Evaporator→ Suction Pipe → Compressor
Refrigerator
Evaporator
PRODUCT SPECIFICATIONS
2-8) Refrigerant Route in Refrigeration cycle
Freezer
Evaporator
Suction Pipe
Capillary Tube
Accumulator
Compressor
Condenser
Hot Pipe
Muffler
