27
DISASSEMBLY AND REASSEMBLY
Water-dispenser
Part Name How To Do Descriptive Picture
1. Assembly shall be the contrary
order from the disassemble.
Case-Rce and Route shall be
assembled inside of hose.
Otherwise, assemble cannot be
accomplished.
2. When assembling Cover-
Display, first insert it from
leftside and then assemble to
rightside.
Otherwise, the tab can be
broken.
3-7) Glass Shelf
Glass Shelf
Part Name How To Do Descriptive Picture
Remove the shelf by lifting the
front plane of the shelf up and
pulling it out.
hose
