Samsung RF267ABBP - 3-22) Freezer Light; 3-23) Door Switch in Freezer

40
DISASSEMBLY AND REASSEMBLY
3-22) Freezer Light
3-23) Door Switch In Freezer
Door Switch In
Freezer
Part Name How To Do Descriptive Picture
1. Remove the freezer drawer bin
by using a flat-blade(-)
screwdriver.(Refer to the
picture)
2. Disconnect the housing
connector part.
Freezer Light
Part Name How To Do Descriptive Picture
1. Remove the light by pulling the
light cover down while pushing
the rear plane of light cover.
AW-BEST_SM(267)-0221 2008.2.21 8:35 PM 페이지40
