24
DISASSEMBLY AND REASSEMBLY
Door Handle
Freezer
Part Name How To Do Descriptive Picture
1. Remove the Cap Door with
using a flat-blade(-) screwdriver.
2.Unscrew 4 screws
3. Lift up the handle to have the
Slider Handle Fre() pushed
back.
4. After having the Slider Handle
Fre() pushed back, screw up
at the hole.
5.Remove the door handle by
lifting it up.
3-3) Refrigerator Door
AW-BEST_SM(267)-0221 2008.2.21 8:32 PM 페이지24
