23
DISASSEMBLY AND REASSEMBLY
Refrigerator
Door
Part Name How To Do Descriptive Picture
5. Lift the door straight up to
remove.
6. With a Philips head screwdriver,
remove the two screws ()
attatched to the lower left and
right door hinges.
With a Wrench(10mm), remove
the 2 Flat head screws ()
attatched to the lower left and
right door hinges.
Remove the lower left and right
door hinges ().
AW-BEST_SM(267)-0221 2008.2.21 8:32 PM 페이지23
To Next Page
