DISASSEMBLY AND REASSEMBLY
3-18) Evaporator In Refrigerator
Evaporator
In Refrigerator
Part Name How To Do Descriptive Picture
1. Remove the the housing cover
by pushing both lateral sides of
the housing cover and pulling it
out.
(Refer to the picture)
2. Disconnect the housing
connector part.
(Refer to the picture)
3. Unscrew 2 screws.
4. Remove the evaporator by lifting
the bottom side of it up and
pulling it out.
(Refer to the picture)
