37
DISASSEMBLY AND REASSEMBLY
3-19) Freezer Door
Freezer
Door
Part Name How To Do Descriptive Picture
1. Pull the drawer open to full
extension.
2. Remove the tilting Pocket(①) by
pulling the both brackets(②)
upward at the same time.
3. Take out the lower basket(③) by
lifting the basket up from rail
system.
4. Remove a fixing pin(④) and
remove a shaft(⑤) by pushing it
to the right side with your hand.
5. Separate the rail from the rail
cover by pushing the hooks (⑥)
in on both sides of the rail. After
pusing the hooks in, remove the
drawer by pulling towards you
with both hands.
①
②
③
⑤
④
AW-BEST_SM(267)-0221 2008.2.21 8:34 PM 페이지37
