DISASSEMBLY AND REASSEMBLY
Power Cord &
Noise Filter
Part Name How To Do Descriptive Picture
1. Unscrew 2 screws.
2. Disengage the housing
connector.
3. Unscrew 3 earth screws.
4. Remove the cover by pushing
the hook up using a flat-blade(-)
screwdriver.
(Refer to the picture)
5. Disengage the housing
connector to separate the power
cord and noise filter.
