Preset Timing Modes
"
This product can be set to only one resolution for each screen size to obtain the optimum picture quality due to the nature of the panel. Using a
resolution other than the specified resolution may degrade the picture quality. To avoid this, it is recommended that you select the optimum resolution
specified for your product.
"
To use a resolution of 3840 x 2160 @ 60 Hz, set Input Signal Plus to On.
Model Name SBB-CX4B / SBB-CV4B / SBB-CS4B
Synchronization
Horizontal Frequency
15 ~ 135 kHz
Vertical Frequency
24 ~ 75 Hz
The screen will automatically be adjusted if a signal that belongs to the following standard signal modes is transmitted from your PC. If the signal
transmitted from the PC does not belong to the standard signal modes, the screen may be blank with the power indicator on. In such a case, change the
settings according to the following table by referring to the graphics card user manual.
Resolution
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
Pixel Clock
(MHz)
Sync Polarity
(H/V)
HDMI 1~2 DP
SDI (SBB-CV4B
model only)
S-Box Grouping
Supported
IBM/VESA, 640 x 480 31.469 59.940 21.175 N / N O O X -
Mac, 640 x 480 35.000 66.667 30.240 N / N O O X -
VESA 640 x 480 37.861 72.809 31.500 N / N O O X -
VESA, 640 x 480 37.500 75.000 31.500 N / N O O X -
IBM, 720 x 400 31.469 70.087 28.322 N / P O O X -
VESA, 800 x 600 37.879 60.317 40.000 P / P O O X -
VESA, 800 x 600 48.077 72.188 50.000 P / P O O X -
VESA, 800 x 600 46.875 75.000 49.500 P / P O O X -
Mac, 832 x 624 49.726 74.551 57.284 N / N O O X -
VESA, 1024 x 768 48.363 60.004 65.000 N / N O O X O
"
Horizontal Frequency
The time required to scan a single
line from the left to the right side
of the screen is called a horizontal
cycle. The reciprocal number of a
horizontal cycle is called horizontal
frequency. Horizontal frequency is
measured in kHz.
"
Vertical Frequency
The product displays a single image
multiple times per second (like a
the viewer sees. The rate of a single
image being displayed repeatedly per
second is called vertical frequency
or refresh rate. Vertical frequency is
measured in Hz.
