Resolution
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
Pixel Clock
(MHz)
Sync Polarity
(H/V)
HDMI 1~2 DP
SDI (SBB-CV4B
model only)
S-Box Grouping
Supported
VESA, 1024 x 768 56.476 70.069 75.000 N / N O O X -
VESA, 1024 x 768 60.023 75.029 78.750 P / P O O X -
VESA, 1152 x 864 67.500 75.000 108.000 P / P O O X -
VESA, 1280 x 720 45.000 60.000 74.250 P / P O O O O
VESA, 1280 x 800 49.702 59.810 83.500 N / P O O X -
VESA, 1280 x 1024 63.981 60.020 108.000 P / P O O X O
VESA, 1280 x 1024 79.976 75.025 135.000 P / P O O X -
VESA, 1440 x 900 55.935 59.887 106.500 N / P O O X -
VESA, 1600 x 900 60.000 60.000 108.000 P / P O O X O
VESA, 1680 x 1050 65.290 59.945 146.250 N / P O O X -
VESA, 1920 x 1080 67.500 60.000 148.500 P / P O O O O
VESA, 2560 x 1440 88.787 59.951 241.500 P / N O O X -
VESA, 3840 x 2160 67.500 30.000 297.000 P / P O O O -
VESA, 3840 x 2160 133.312 59.997 533.250 P / N O O X -
CEA-861 VIC 3, 720x480 31.469 59.940 27.000 N / N O O O -
CEA-861 VIC 4, 1280x720 45.000 60.000 74.250 P / P O O O O
CEA-861 VIC 5, 1920x1080i 33.750 60.000 74.250 P / P O X O -
CEA-861 VIC 7, 720(1440)x480i 31.469 59.940 27.000 P / P O X O -
CEA-861 VIC 16, 1920 x 1080 67.500 60.000 148.500 P / P O O O O
CEA-861 VIC 18, 720x576 31.250 50.000 27.000 N / N O O O O
CEA-861 VIC 19, 1280x720 37.500 50.000 74.250 P / P O O O O
