80
Resolution
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
Pixel Clock
(MHz)
Sync Polarity
(H/V)
HDMI 1~2 DP
SDI (SBB-CV4B
model only)
S-Box Grouping
Supported
CEA-861 VIC 20, 1920x1080i 28.125 50.000 47.250 P / P O X O -
CEA-861 VIC 22, 720(1440)x576i 31.250 50.000 27.000 P / P O X O -
CEA-861 VIC 31, 1920x1080 56.250 50.000 148.500 P / P O O O O
CEA-861 VIC 32, 1920x1080 27.000 24.000 74.250 P / P O O O -
CEA-861 VIC 33, 1920x1080 28.125 25.000 74.250 P / P O O O -
CEA-861 VIC 34, 1920x1080 33.750 30.000 74.250 P / P O O O -
CEA-861 VIC 93, 3840x2160 54.000 24.000 297.000 P / P O O O -
CEA-861 VIC 94, 3840x2160 56.250 25.000 297.000 P / P O O O -
CEA-861 VIC 95, 3840x2160 67.500 30.000 297.000 P / P O O O -
CEA-861 VIC 96, 3840x2160 112.500 50.000 594.000 P / P O O O O
CEA-861 VIC 97, 3840x2160 135.000 60.000 594.000 P / P O O O O
