40_ maintain
EMPTYING THE AUTO-EMPTIER DUSTBIN
Remove the dustbin in the direction of the arrow.1.
Slide the locking bar downward to open the dustbin cover.2.
Open the cover after positioning the dustbin over a wastebasket.
❈
Slide the locking bar downward to open the dustbin cover.
Shake the dust from the dustbin.3.
Close the dustbin cover until it clicks into place, and then 4.
reassemble the dustbin on the main body.
CLEANING THE CYCLONE OF THE AUTO-EMPTIER DUSTBIN
1
2
3
Remove the dustbin and
rotate and open the cyclone
cover in the direction of the
arrow.
Remove any foreign
substances from the inside of
the cyclone.
After cleaning, rotate and
close the cyclone cover in the
direction of the arrow.
Click
DJ68-00632D(0.0).indd 40DJ68-00632D(0.0).indd 40 2012.1.19 9:50:43 AM2012.1.19 9:50:43 AM
