Diagram
88
18,000BTU
Indoor Unit
1/2”
5/8”
1/2”
Valve Packed 1/2” Valve Packed 1/4”
C-Capi
Air-in
Air-in
1/2”
1/4”
1/4”
1/4”
Outdoor Unit
00150A(2)-54~98 2/5/01 11:54 AM Page 88
