Samwon Tech TEMI1000 Series - Page 23

21
[Fig.3-15]Screenforpatternnumbersettinginputkeytobeoperated
References
▶Whenthebuttonistouchedbyforinputting
thepatternnumbersettingtobeoperated,itisactivatedas
shownin[Fig.3-15]Screenforpatternnumbersettinginput
keytobeoperated.
▶Executetheprogrambyselectingbuttonwhentheinput
forthepatternnumbersettingtobeoperatediscompleted.
03. Operation state screen setting
Parameter Initial value
Patternnumber
Setting range Unit
1~120 ABS 1
●Itisnotoperatedwhentheprogramisnotinputintothe
patternnumberonthescreen.
●Referto[7-1Programpatternsetting]
Cautions in operation
